WCCTV Mini Dome Solar Trailer + LPR combines autonomously-powered rapid deployment mobile video surveillance with license plate recognition technology.

It takes just minutes to install the WCCTV Mini Dome Solar Trailer at your locations, and it can easily be moved as your surveillance applications change.

It is an ideal surveillance system for locations without any fixed infrastructure for power or video transmission and can assist with applications such as traffic management, illegal dumping, access control, project management and job site security.

The trailer is fitted with up to 4 cameras, including WCCTV Pole Cameras and LPR cameras.

All live and recorded footage is accessed via 4G LTE, 3G and Wi-Fi connectivity, so users can remotely view and download video via smartphone, tablet, computer or from a video management system.

The WCCTV Mini Dome Solar Trailer + LPR is ideal for security and project management applications, including data collection along highways, entrances to buildings, job sites and other secure facilities. It is also an ideal crime-fighting tool against illegal dumping and traffic or parking violations.

The trailer features a telescoping 20ft tower which rotates nearly 360 degrees, and is equipped with highly reliable 260W, 390W or 520W autonomous solar power which is suitable for most locations.

The system weighs less than 1400 lbs, making it towable by most vehicles.

Features and Benefits

  • All-in-one rapid deployment mobile surveillance trailer

  • LPR Camera included

  • Compact and easy to transport

  • High definition video (up to 1080p)

  • 4G LTE, 3G, Wi-Fi and IP connectivity

  • 20-foot tower - rotates nearly 360 degrees

  • Silent operation

  • Year-round autonomy

  • Environmentally Tested

  • Fix -Power-Walk Away

  • Fully operational within 20 minutes

  • Full remote configuration

  • Easy to support

  • Multiple remote connectivity options

  • No geographical restrictions

  • Time Lapse Video ready


  • Jobsite security

  • Temporary works

  • Asset protection

  • Major public events

  • Cable and metal theft

  • Project management

  • Health and safety

  • Works in progress


Transmission methods

  • 4G/LTE (with fall back to 3G)

  • Wi-Fi (Long range up to 2km, short-range 100m)

Purchase Information

The WCCTV Mini Dome Solar Trailer + LPR is available on a sale or rental basis, for more information please complete a contact form.

Alternatively you can contact WCCTV on +1 877 805-9475 or

Dimensions (HxWxD) - 283.4" x 55.1" x 61.8" - deployed
Operating Temperature Range -22 to 122°F
Power 110-240 Volt input (mains powered) 12 Volt DC (battery powered)
Power Consumption 24W @ 240V
Weight 820lbs
Software Upgrade Internet / 4G/LTE / 3G / Back to Back PC


Video Inputs 4
Operation Simultaneous live, record, playback, remote access
Optical/Digital Zoom 44x / 28x / 18x
Resolution of Camera 1080p
Maximum FPS 25
Recording Proprietary narrowband algorithm
MutiMode (recording algorithms)     Dynamically changes record rates and compression settings for the camera
Snapshot Video Clip Yes
Video Motion Search Yes
Archive Protection Yes - protect against overwriting
Wireless Communication Supported via suitable interface - GSM, GPRS, UMTS, HSDPA, HSCSD, 3G, 4G/LTE


Maximum Internal Capacity     Up to 4TB
Hard Disk Drive Types Removable SATA hard disk drive
Export 4G/LTE / HSUPA / Network / Optional removable SATA Drive


Alarm Function Support Alarm log, event search, pre-event recording
Alarm Reporting Yes - to a remote site via email
Display Alarm on PC Monitor       Yes or network / HSUPA / 4G/LTE
Video Motion Detection Yes


Remote PTZ Control Yes
Bandwidth Management Yes
Remote Administration Yes
Remote PC Client                Client Software Free Download
Remote Web Browser Client Viewing
Password Protected Yes
Smartphone Compatible Yes
Tablet Compatible Yes
