WCCTV Mini Dome Solar Trailer + LPR

View all category:

LPR

Make an Inquiry
Product Information
Product Specification

WCCTV Mini Dome Solar Trailer + LPR combines autonomously-powered rapid deployment mobile video surveillance with automatic license plate recognition technology.

It takes just minutes to install the WCCTV Mini Dome Solar Trailer at your locations, giving you eyes on the ground, and it can easily be moved as your surveillance applications change.

It is an ideal surveillance system for locations without any fixed infrastructure for power or video transmission. It can assist with parking lot security, traffic management, illegal dumping, access control, project management and job site security.

The trailer is fitted with up to 4 cameras, including WCCTV Pole Cameras and LPR cameras.

All live and recorded footage is accessed via 4G LTE, 3G and Wi-Fi connectivity, so users can remotely view and download video any time via any device.

The solution's LPR capability makes it ideal for security and project management applications, including data collection along highways, entrances to buildings, job sites, or commercial parking lots. It is also an ideal crime-fighting tool against illegal dumping and traffic or parking violations.

The trailer features a telescoping 20ft tower that rotates nearly 360 degrees, and is equipped with highly reliable 260W, 390W or 520W autonomous solar power, which is suitable for most locations.

Read more on the benefits of Rapid Deployment Trailers

Features and Benefits

  • All-in-one rapid deployment mobile surveillance trailer

  • LPR Camera included

  • Compact and easy to transport

  • Quick and easy to install - 20 minute / 1 person

  • Integrated 4G LTE connectivity

  • High definition video (up to 1080p)

  • Remote access to cameras any time from any device

  • 20-foot tower - rotates nearly 360 degrees

  • Silent operation

  • Year-round autonomy

  • Environmentally Tested

  • Fix -Power-Walk Away

  • Free and unlicensed viewing software

  • Full remote configuration

  • Easy to support

  • Integrated 4TB SSD internal storage

  • No geographical restrictions

  • Time Lapse Video ready

49055261232_299baa1b58_o

Transmission methods

WCCTV provides the most competitive data packages, with all products specifically designed for the secure transmission of video over cellular networks using private VPN.

  • 4G LTE

  • Wi-Fi (Long range up to 2km, short-range 100m)

Purchase Information

The WCCTV Mini Dome Solar Trailer + LPR is available on a sale or rental basis, for more information please complete a contact form.

Alternatively you can contact WCCTV on +1 877 805-9475 or sales@wcctv.com

General
Dimensions (HxWxD) - 283.4" x 55.1" x 61.8" - deployed
Operating Temperature Range -22 to 122°F
Power 110-240 Volt input (mains powered) 12 Volt DC (battery powered)
Power Consumption 24W @ 240V
Weight 820lbs
Software Upgrade Internet / 4G/LTE / 3G / Back to Back PC



Video
Video Inputs 4
Operation Simultaneous live, record, playback, remote access
Optical/Digital Zoom 44x / 28x / 18x
Resolution of Camera 1080p
Maximum FPS 25
Recording Proprietary narrowband algorithm
MutiMode (recording algorithms)     Dynamically changes record rates and compression settings for the camera
Snapshot Video Clip Yes
Video Motion Search Yes
Archive Protection Yes - protect against overwriting
Wireless Communication Supported via suitable interface - GSM, GPRS, UMTS, HSDPA, HSCSD, 3G, 4G/LTE



Storage
Maximum Internal Capacity     Up to 4TB
Hard Disk Drive Types Removable SATA hard disk drive
Export 4G/LTE / HSUPA / Network / Optional removable SATA Drive



Alarms
Alarm Function Support Alarm log, event search, pre-event recording
Alarm Reporting Yes - to a remote site via email
Display Alarm on PC Monitor       Yes or network / HSUPA / 4G/LTE
Video Motion Detection Yes



Networking
Remote PTZ Control Yes
Bandwidth Management Yes
Remote Administration Yes
Remote PC Client                Client Software Free Download
Remote Web Browser Client Viewing
Password Protected Yes
Smartphone Compatible Yes
Tablet Compatible Yes
