WCCTV 4G HD Mini Dome

View all category:

Pole Cameras

Make an Inquiry
Product Information
Product Specification

WCCTV’s 4G HD Mini Dome is a rapid deployment pole camera specifically designed for mobile video surveillance applications including Law Enforcement, construction site security, city safety and parking lot security.

As an all-in-one portable video surveillance solution, the 4G HD Mini Dome combines a PTZ camera, 4TB of onboard recording capacity and cellular transmission technology into a compact, lightweight unit.

The system is easy to install and maintain, and can be quickly moved to new locations to target crime hotspots or deliver surveillance on demand.

Live and recorded video is delivered via 4G LTE, 3G and Wi-Fi connectivity, making it easy to remotely view and download the video any time from any device.

The WCCTV 4G HD Mini Dome also contains video analytics functionality providing verification and alerts allowing for automated and intelligent surveillance.

The unit's additional input channel allows for the addition of a secondary security camera such as an LPR camera, PTZ camera or static camera for Time Lapse Video applications. Secondary cameras can share the recording capacity and LTE connectivity of the 4G HD Mini Dome.

The additional input channel can also be utilized for the addition of accessories such as solar packs or the WCCTV Blue Light alarm system.

Read more on the benefits of Rapid Deployment Pole Cameras

Features and Benefits

  • Rapid deployment mobile surveillance system

  • Portable solution to target crime hotspots

  • High definition video (up to 1080p)

  • 4G LTE, 3G, Wi-Fi and IP connectivity

  • Remote access - anytime from any device

  • Inbuilt video analytics for intelligent surveillance

  • Remote control and configuration of PTZ functionality, pre-sets and auto-tours

  • Low power usage

  • High-speed live streaming - up to 25 FPS

  • ONVIF compatible

  • Easy to install and easy to maintain - fix-power-walk away

  • Lightweight unit (9 lbs)

  • Multiple powering options: mains (110-240v ac 12v ac-dc), battery pack, solar panel or solar trailer

  • Additional input channel - add LPR cameras and accessories

  • Time Lapse Video ready

  • Integrates with most video management platforms

  • Environmentally tested (IP65 rated)

  • Up to 4TB internal storage

Applications

WCCTV Pole Cameras - 4G HD Mini Dome

WCCTV Pole Cameras - 4G HD Mini Dome - Back View - Secondary Input

Transmission methods

WCCTV provides the most competitive data packages, with all products specifically designed for the secure transmission of video over cellular networks.

  • 4G LTE (with fall back to 3G)

  • IP/Broadband

  • LAN-only

  • Wi-Fi (Long range up to 2km, short-range 350 ft)

Purchase Information

For purchase information please complete a contact form.

Alternatively you can contact WCCTV on +1 877 805-9475 or sales@wcctv.com

General
Dimensions (HxWxD) 13.7" x 7.5" x 7"
Operating Temperature Range -22 to +122°F
Power 110-240 Volt input (mains powered) 12 Volt DC (battery powered)
Power Consumption 24W (mains powered)
Weight 13lbs
Software Upgrade Internet / 4G / 3G / Back to Back PC



Video
Video Inputs 2
Operation Simultaneous live, record, playback, remote access
Optical/Digital Zoom 20x Optical, 16x Digital
Resolution of Camera 1080p, 720p, 800 x 600
Maximum FPS 25
Recording Proprietary narrowband algorithm
Multimode (recording algorithms)     Dynamically changes record rates and compression settings for the camera
Snapshot Video Clip Yes
Video Motion Search Yes
Archive Protection Yes - protect against overwriting
Wireless Communication Supported via suitable interface - GSM, GPRS, UMTS, HSDPA, HSCSD, 3G, 4G



Storage
Maximum Internal Capacity     Up to 4TB
Hard Disk Drive Types Removable SATA hard disk drive
Export 4G / HSUPA / Network / Optional removable SATA Drive



Alarms
Alarms 2 camera control, 1 alarm, 1 arming / disarming and 1 auxiliary inputs
Alarm Function Support Alarm log, event search, pre-event recording
Alarm Reporting Yes - to a remote site via email
Display Alarm on PC Monitor       Yes or network / HSUPA / 4G
Relays 2 relays - system error and/or remote control purposes
Video Motion Detection Yes



Networking
Remote PC Client                Client Software Free Download
Remote Web Browser Client Viewing
Password Protected Yes
Smartphone Compatible Yes
Tablet Compatible Yes
