WCCTV’s combined rapid deployment pole camera and LPR system utilizes a WCCTV Pole Camera's additional input channels to integrate a specialized License Plate Recognition Camera.

This unique all-in-one mobile video surveillance system combines all the benefits of WCCTV's pole camera range with automatic licence place recognition technology for a range of crime reduction and security applications.

The system harnesses the 4G LTE, local recording (up to 4TB) and 360° PTZ field of vision of the WCCTV Mini Dome to provide a complete situational overview. Simultaneously, the LPR camera delivers crystal-clear images of license plates in all weather and lighting conditions.

The LPR camera captures and stores images of license plates, and converts them into a text database.

The Benefits of LPR Cameras

This database can be accessed and downloaded remotely, providing full statistical analysis and/or allowing the searching of a license plate or activity during a specific period of time.

The WCCTV Mini Dome + LPR is ideal for security and project management applications, including data collection along highways, entrances to buildings, job sites or other secure facilities. It is also an ideal crime-fighting tool against illegal dumping and traffic or commercial parking lots.

The camera can read license plates day and night, in any weather condition on vehicles travelling up to 130mph.

Read more on the benefits of Rapid Deployment Pole Cameras

Features and Benefits

  • Combined pole camera and LPR solution

  • LPR vehicle license plate scanning / real time alerting

  • Integrated 4G LTE video transmission

  • Day/night operation in any weather

  • Rapidly deployable, easy to install - plug and play

  • Completely portable, tackle crime hotspots

  • Full HD video images

  • Built-in self-testing diagnostics

  • Remote access to live and recorded video any time from any device

  • Remote control with full 360° pan, tilt & zoom functionality (Mini Dome)

  • Integrated 4TB SSD internal storage

  • Environmentally tested vandal resistant enclosure

  • Direct connect to nationally hosted LPR data server

  • Includes car detector LPR software for local server hosting

  • Full suite of LPR tools including data analytics

  • Remote power cycle option

WCCTV 4G IR Mini Dome + LPR Camera - Pole Cameras - Law Enforcement

Transmission methods

WCCTV provides the most competitive data packages, with all products specifically designed for the secure transmission of video over cellular networks using private VPN.

  • 4G LTE

  • IP/Broadband

  • LAN-only

  • Wi-Fi (Long range up to 2km, short-range 100m)

Purchase Information

For purchase information please complete a contact form.

Alternatively you can contact WCCTV on +1 877 805-9475 or sales@wcctv.com

General
Dimensions (HxWxD) 27.5" x 5.9" x 8.8"
Operating Temperature Range -22 to 122°F
Power 110-240 Volt input (mains powered) 12 Volt DC (battery powered)
Power Consumption WCCTV Dome - 24W @ 240V / LPR - 15W Max
Weight WCCTV Dome 14lbs / LPR 8.1 lbs
Software Upgrade Internet / 4G/LTE / 3G / Back to Back PC



Video
Video Inputs 4
Operation Simultaneous live, record, playback, remote access
Optical/Digital Zoom 30x Optical / 12x Digital
Resolution of Camera 1080p
Maximum FPS 25
Recording Proprietary narrowband algorithm
MutiMode (recording algorithms)     Dynamically changes record rates and compression settings for the camera
Snapshot Video Clip Yes
Video Motion Search Yes
Archive Protection Yes - protect against overwriting
Wireless Communication Supported via suitable interface - GSM, GPRS, UMTS, HSDPA, HSCSD, 3G, 4G/LTE



Storage
Maximum Internal Capacity     Up to 4TB
Hard Disk Drive Types Removable SATA hard disk drive
Export 4G / HSUPA / Network / Optional removable SATA Drive



Alarms
Alarms 2 camera control, 1 alarm, 1 arming / disarming and 2 auxiliary inputs
Alarm Function Support Alarm log, event search, pre-event recording
Alarm Reporting Yes - to a remote site via email
Display Alarm on PC Monitor       Yes or network / HSUPA / 4G/LTE
Relays 2 relays - system error and/or remote control purposes
Video Motion Detection Yes



Networking
Remote PC Client                Client Software Free Download
Remote Web Browser Client Viewing
Password Protected Yes
Smartphone Compatible Yes
Tablet Compatible Yes
